58
Chapter 4 Inspection
VISERA VIDEO SYSTEM CENTER OTV-S7V
4.7 Picture in picture image inspection (type C only;
see Section 2.5)
Refer to Section 5.26, “Picture in picture”. Confirm that images from the video
input terminal are inserted into the endoscopic image on the video monitor.
4.8 Multi freeze image inspection (installed in
OTV-S7BOD-MF type only)
Refer to Section 5.27, “Multi freeze”. Confirm that multi freeze images are
displayed on the video monitor.
4.9 Image orientation inspection (type F and
installed in OTV-S7BOD-RT type only)
Refer to Section 5.28, “Orientation”. Confirm that normal or rotated images are
displayed properly on the video monitor.
