162
Chapter 5 Operation
VISERA VIDEO SYSTEM CENTER OTV-S7V
5.25 Mirror and rotated images (type C only; see
Section 2.5)
The image displayed on the video monitor can be rotated 180 and mirrored
around its vertical axis by controlling the menu switches or keyboard (optional).
• 180 DEG. ROTATION : display a rotated 180 image
• MIRROR : display a mirrored around its vertical image
• NORMAL : display a normal image
The menu and patient data are not displayed on the images
that is transmitted via the reverse terminal.
Change the image quickly (keyboard only)
1. Refer to Section 5.13, “Setting a function to the keyboard” and set
“REVERSE” to the “B.O.D.” key.
2. Press the “B.O.D.” key that is set to “REVERSE”. Each time this switch is
depressed, the image cycles through “180 DEG. ROTATION”, “MIRROR”
and “NORMAL”.
Change the image by operating the menu
1. Depress the menu switch “ ” for approximately 1 second or the “F1” key
on the keyboard to display the menu.
By simultaneously pressing the keyboard’s “Shift” key and
“B.O.D.” key that is set to “REVERSE”, you can jump to step
7. For instructions on setting the “B.O.D.” key to “REVERSE”,
refer to Section 5.13, “Setting a function to the keyboard”.
2. Depress the menu switches “ ” or “ ”, or the “///” key on the
keyboard to move the arrow “ ” to “B.O.D. CONTROL” (see Figure 5.89).
3. Depress the menu switch “ ” or the “Enter” key on the keyboard to display
the next menu.
4. Depress the menu switches “ ” or “ ”, or the “///” key on the
keyboard to move the arrow “ ” to “REVERSE IMAGE” (see Figure 5.111).
To Next Page
