Appendix A
A-54
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
DB_ControlService (Control DB Connection Service)
The DB_ControlService instruction starts/stops the DB Connection Service or starts/finishes recording
to the Debug Log.
Instruction
Name
FB/FUN
Graphic expression
ST expression
DB_ControlService Control DB
Connection
Service
FB
DB_ControlService_instance
(Execute, Cmd, Done, Busy,
Error, ErrorID);
Note The DB_ControlService_instance is an instance of DB_ControlService instruction, which is declared as a variable.
Variables
Input Variables
Name
Meaning
Data type
Valid range
Unit
Default
Description
Execute Execute BOOL TRUE or FALSE --- FALSE Specify the execution
condition.
Cmd Command _eDBC_CMD _DBC_CMD_START(1):
Start the service in Operation Mode
_DBC_CMD_START_TEST(2):
Start the service in Test Mode
_DBC_CMD_STOP(3): Stop the service
_DBC_CMD_DEBUGLOG_ON(4):
Start recording to Debug Log
_DBC_CMD_DEBUGLOG_OFF(5):
Finish recording to Debug Log
0 Specify the command to
execute
Output Variables
Name
Meaning
Data type
Valid range
Unit
Description
Done Done BOOL TRUE or
FALSE
--- TRUE when the instruction is normally
completed.
Busy Executing BOOL TRUE or
FALSE
--- TRUE when the instruction is being executed.
Error Error BOOL TRUE or
FALSE
--- TRUE when the instruction is terminated due to
an error.
ErrorID Error Code WORD 16#0000 to
16#FFFF
--- Contains the error code when an error occurs.
DB_ControlService
Busy
Execute
Done
Error
ErrorID
Cmd
DB_ControlService_instance

Omron NX701-1620 Specifications

General

Model	NX701-1620
Type	CPU Unit
Power Supply	24 VDC
Programming Software	Sysmac Studio
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 70°C
Series	NX Series
Digital Inputs	Dependent on I/O modules
Digital Outputs	Dependent on I/O modules
Communication Ports	Ethernet
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s², 3 times each in X, Y, and Z directions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude; 57 to 150 Hz, 9.8 m/s² acceleration
