NJ/NX-series Database Connection CPU Units User’s Manual (W527)
DB_PutLog (Record Operation Log)
The DB_PutLog instruction puts a user-specified record into the Execution Log or Debug Log.
Instruction
Name
FB/FUN
Graphic expression
ST expression
DB_PutLog Record
Operation Log
FB
DB_PutLog_instance (Execute,
LogType, LogCode, LogName,
LogMsg, Done, Busy, Error,
ErrorID);
Note The DB_PutLog_instance is an instance of DB_PutLog instruction, which is declared as a variable.
Variables
Input Variables
Name
Meaning
Data type
Valid range
Unit
Default
Description
Execute Execute BOOL TRUE or FALSE --- FALSE Specify the
execution condition.
LogType Log Type _eDBC_LOGTYPE _DBC_LOGTYPE_EXECUTION(1):
Execution Log
_DBC_LOGTYPE_DEBUG(2):
Debug Log
0 Specify the type of
log to output
LogCode Log Code INT 0 to 9999 --- 0 Specify the code to
record in the log.
LogName Log Name STRING 33 bytes max. (including the final
NULL character)
--- '' Specify the name to
record in the log.
LogMsg Log Message STRING 129 bytes max. (including the final
NULL character)
--- '' Specify the message
to record in the log.
Output Variables
Name
Meaning
Data type
Valid range
Unit
Description
Done Done BOOL TRUE or
FALSE
--- TRUE when the instruction is normally
completed.
Busy Executing BOOL TRUE or
FALSE
--- TRUE when the instruction is being executed.
Error Error BOOL TRUE or
FALSE
--- TRUE when the instruction is terminated due to
an error.
ErrorID Error Code WORD 16#0000 to
16#FFFF
--- Contains the error code when an error occurs.
ErrorID
DB_PutLog
LogType Busy
Execute
Done
Error
LogCode
LogName
LogMsg
DB_PutLog_instance

Omron NX701-1620 Specifications

General

Model	NX701-1620
Type	CPU Unit
Power Supply	24 VDC
Programming Software	Sysmac Studio
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 70°C
Series	NX Series
Digital Inputs	Dependent on I/O modules
Digital Outputs	Dependent on I/O modules
Communication Ports	Ethernet
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s², 3 times each in X, Y, and Z directions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude; 57 to 150 Hz, 9.8 m/s² acceleration
