3 Programming the DB Connection Function
3-25
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
3
3-5 Programming and Transfer
3-5-4 System-defined Variables
3-5-4 System-defined Variables
You can use the following system-defined variable in the DB Connection Service.
Common Variables of NX701-@@20, NJ501-@@20, and NJ101-@@20
Variable name
Data type Meaning Function
Initial
value
Member name
_DBC_Status _sDBC_STATUS DB Connection
Service Status
Shows the operation status of the
DB Connection Service.
Refer to 4-3-1 Operation Status of
the DB Connection Service for
details on the operation status of
the DB Connection Service.
Run BOOL Running flag TRUE when the DB Connection
Service is running in Operation
Mode or Test Mode.
FALSE
Test BOOL Test Mode TRUE when the DB Connection
Service is running in Test Mode.
FALSE
Idle BOOL Idle TRUE when the operation status of
the DB Connection Service is Idle.
FALSE
Error BOOL Error Stop Flag TRUE when the operation status of
the DB Connection Service is
Error.
FALSE
Shutdown BOOL Shutdown TRUE when the operation status of
the DB Connection Service is
Shutdown.
FALSE
NX701-@@20
Variable name
Data type
Name
Function
_DBC_Version ARRAY[0..1] OF
USINT
DB Connection
Service version
The DB Connection Service version is stored. *1
The integer part of the version is stored in the
element number 0.
The decimal part of the version is stored in the
element number 1.
_JRE_Version ARRAY[0..1] OF
USINT
JRE version The JRE version is stored. *2
The integer part of the version is stored in the
element number 0.
The decimal part of the version is stored in the
element number 1.
*1 Example 1) In the case of the DB connection service version 1.00, “1“ is stored in the
element number 0 and “0“ is stored in the element number 1.
Example 2) In the case of the DB connection service version 1.10, 1 is stored in the element
number 0 and “10” is stored in the element number 1.
*2 Example 1) In the case of the JRE version 1.00, “1” is stored in the element number 0 and
“0” is stored in the element number 1.
Example 2) In the case of the JRE version 1.10, “1” is stored in the element number 0 and
“10” is stored in the element number 1.

Omron NX701-1620 Specifications

General

Model	NX701-1620
Type	CPU Unit
Power Supply	24 VDC
Programming Software	Sysmac Studio
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 70°C
Series	NX Series
Digital Inputs	Dependent on I/O modules
Digital Outputs	Dependent on I/O modules
Communication Ports	Ethernet
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s², 3 times each in X, Y, and Z directions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude; 57 to 150 Hz, 9.8 m/s² acceleration
