2-1 Starting Sysmac Studio and
Creating a New Project
This section describes how to start Sysmac Studio and create a new project when using the DB
Connection function.
Refer to the Sysmac Studio Version 1 Operation Manual (Cat. No. W504) for detailed operations.
Refer to B-4 Version Information for correspondence between CPU Unit and DB Connection
Service versions and between CPU Unit and Sysmac Studio versions.
2-1-1 Starting Sysmac Studio
1. Install the following Sysmac Studio.
ï‚– NX701-@@20: Version 1.21 or higher
ï‚– NJ501-@@20 or NJ101-@@20: Version 1.14 or higher
2. Start Sysmac Studio.
2-1-2 Creating a New Project
1. Select one of the following devices in the Device Field of the Select Device Area.
NX701: 1720 or 1620
NJ501: 1320, 1420, or 1520
NJ101: 1020 or 9020
To Next Page
