Omron NX701-1620 User Manual

3 Programming the DB Connection Function
3-24
NJ/NX-series Database Connection CPU Units User’s Manual (W527)
3-5-3 DB Connection Instruction Set
Instruction
Name
Function
DB_Connect Establish DB
Connection
Connects to a specified DB.
DB_Close Close DB
Connection
Closes the connection with the DB
established by a DB_Connect
(Establish DB Connection)
instruction.
DB_CreateMapping Create DB Map Creates a mapping from a DB Map
Variable to a table of a DB.
DB_Insert Insert DB Record Inserts values of a DB Map Variable
to a table of the connected DB as a
record.
DB_Update Update DB Record Updates the values of a record of a
table with the values of a DB Map
Variable.
DB_Select Retrieve DB
Record
Retrieves records from a table to a
DB Map Variable.
DB_Delete Delete DB Record Deletes the records that match the
conditions from a specified table.
DB_ControlService Control DB
Connection Service
Starts/stops the DB Connection
Service or starts/finishes recording to
the Debug Log.
DB_GetServiceStatus Get DB Connection
Service Status
Gets the current status of the DB
Connection Service.
DB_GetConnectionStatus Get DB Connection
Status
Gets the status of a DB Connection.
DB_ControlSpool Resend/Clear
Spool Data
Resends or clears the SQL
statements spooled by DB_Insert
(Insert DB Record) and DB_Update
(Update DB Record) instructions.
DB_PutLog Record Operation
Log
Puts a user-specified record into the
Execution Log or Debug Log.
DB_Shutdown Shutdown DB
Connection Service
Shuts down the DB Connection
Service.
* Be sure to execute a DB_Shutdown (Shutdown DB Connection Service) instruction before you turn OFF
the power supply to the system. If the power supply is turned OFF without executing a DB_Shutdown
(Shutdown DB Connection Service) instruction, the Operation Log file may be corrupted or its contents
may be lost.
Refer to Appendix DB Connection Instructions for details and sample programming of each
instruction.

Omron NX701-1620 Specifications

General

Model	NX701-1620
Type	CPU Unit
Power Supply	24 VDC
Programming Software	Sysmac Studio
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 70°C
Series	NX Series
Digital Inputs	Dependent on I/O modules
Digital Outputs	Dependent on I/O modules
Communication Ports	Ethernet
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s², 3 times each in X, Y, and Z directions
Vibration Resistance	10 to 57 Hz, 0.075 mm amplitude; 57 to 150 Hz, 9.8 m/s² acceleration

Summary

Introduction

Intended Audience

Specifies the target audience for this manual, requiring knowledge of electrical systems and FA.

Applicable Products

Lists the specific CPU Unit models and Sysmac Studio versions covered by this manual.

Relevant Manuals

Manual Structure

Page Structure

Details the components of a typical page, including headings, procedures, and icons.

Special Information

Precautions for Safe Use

Outlines precautions to ensure the safe usage of the product.

Precautions for Correct Use

Provides precautions for ensuring proper operation and performance of the product.

Additional Information

Offers extra details to enhance understanding or make operations easier.

Version Information

Details differences in specifications and functionality based on unit and Sysmac Studio versions.

Precaution on Terminology

Defines key terms like "download" and "synchronize" as used in the manual.

Sections in this Manual

Terms and Conditions Agreement

Warranty, Limitations of Liability

Details Omron's warranty terms, limitations, and buyer remedies for product defects.

Limitation on Liability; Etc

Limits Omron's liability for damages related to product use or consequential losses.

Application Considerations

Discusses suitability of use, programmable products, and critical safety considerations for applications.

Disclaimers

Covers performance data, specification changes, and errors/omissions.

Programmable Products

Clarifies Omron's non-responsibility for user programming of programmable products.

Performance Data

Explains that presented performance data is a guide and not a warranty.

Change in Specifications

States that product specifications may change without notice.

Errors and Omissions

Disclaims responsibility for clerical, typographical, or proofreading errors or omissions in the manual.

Safety Precautions

Precautions for Safe Use

Refers to hardware manuals for safety precautions and provides contact information for specific models.

Precautions for Correct Use

Regulations and Standards

Conformance to EU Directives

Details how NJ/NX-series Controllers comply with EU Directives and installation requirements.

Conformance to KC Standards

Provides precautions for using NX-series Units in Korea, noting Class A device registration.

Conformance to Shipbuilding Standards

Explains compliance with shipbuilding standards, including usage conditions for NK and LR standards.

Software Licenses and Copyrights

Informs about third-party software licenses and copyright information availability.

Versions

Unit Versions

Defines unit versions for hardware/software of Units and EtherCAT slaves.

Version Types

Describes the two types of versions: unit version and DB Connection Service version.

Checking Versions

Details methods for checking unit versions using ID information labels and Sysmac Studio.

Unit Versions of CPU Units and Sysmac Studio Versions

Relates supported functions to CPU Unit and Sysmac Studio versions, referring to B-4.

Related Manuals

Terminology

Revision History

Introduction to the DB Connection Service

1-1 Overview and Features

Introduces the DB Connection Service, its overview, and key features.

1-2 DB Connection Service Specifications and System

Details the specifications and system architecture of the DB Connection Service.

1-3 Operation Flow of the DB Connection Service

Outlines the basic operational flow for using the DB Connection Service.
