NJ/NX-series Database Connection CPU Units User’s Manual (W527)
DB_GetServiceStatus (Get DB Connection Service
Status)
The DB_GetServiceStatus instruction gets the current status of the DB Connection Service.
Instruction
Name
FB/FUN
Graphic expression
ST expression
DB_GetService
Status
Get DB
Connection
Service Status
FB
DB_GetServiceStatus_instance
(Execute, Done, Busy, Error,
ErrorID, ServiceStatus);
Note The DB_GetServiceStatus_instance is an instance of DB_GetServiceStatus instruction, which is declared as a variable.
Variables
Input Variables
Name
Meaning
Data type
Valid range
Unit
Default
Description
Execute Execute BOOL TRUE or FALSE --- FALSE Specify the execution
condition.
Output Variables
Name
Meaning
Data type
Valid range
Unit
Description
Done Done BOOL TRUE or
FALSE
--- TRUE when the instruction is normally
completed.
Busy Executing BOOL TRUE or
FALSE
--- TRUE when the instruction is being
executed.
Error Error BOOL TRUE or
FALSE
--- TRUE when the instruction is terminated
due to an error.
ErrorID Error Code WORD 16#0000 to
16#FFFF
--- Contains the error code when an error
occurs.
ServiceStatus DB Connection
Service Status
_sDBC_SERVICE_STATUS Depends on
the data type.
Shows the status of the DB Connection
Service.
DB_GetServiceStatus
Busy
Execute
Done
Error
ErrorID
ServiceStatus
DB_GetServiceStatus_instance
