Operator’s Manual - OPTI CCA-TS2 6-9
6 DATA MANAGEMENT
6.2.3 Controls Diagnostics Reports
The <Controls Diagnostics Report> contains
information about the measured signal in femtowatts
and drifts observed during measurement.
You can print out reports of individual control
measurements, groups of control measurements,
or all the measurements in memory.
1. To print a Controls Diagnostics Report, select
<Data Manager> in the main menu.
2. In the <Data> screen, press the
<Diagnostics> tab and select <Controls>
(Fig. 6-21).
3. In the <Data - Control Diagnostics> screen
(Fig. 6-22), select the desired measurement and
press the <View> button
to display the
measurement results (Fig. 6-23).
4. Use the <Previous> and <Next>
buttons to display the previous or next page of
measurements.
5. To print individual results, highlight the desired
measurement (Fig. 6-22).
6. To print groups of results, highlight the rst
measurement to be printed, press <Mark>
and select the last measurement to be printed.
All the measurements in between will be
selected.
7. Press <All> to select all results.
8. Press <Print> to print your selection.
9. Press to return to the <Data> screen or
to return to the main menu.
Fig. 6-22 Select Measurement
Fig. 6-21 Select Control
Fig. 6-23 Control Diagnostics
