OPTi CCA-TS2 User Manual

8-28 Operator’s Manual – OPTI CCA-TS2
8 DIAGNOSTICS AND TROUBLESHOOTING
8.2.17 Checking the Display
The purpose of this test is to check the proper
operation of the display.
In the main menu, press <System Manager ->
Diagnostics>.
• Select the <Tests> tab.
•
Press <Display> to start the test (Fig. 8-29).
• The display will turn red, green and blue.
If this is not the case, your display is defective
and needs to be replaced.
• Press
to return to the <System> screen
or
to return to the main menu.
Fig. 8-29 Display Test
8.2.16 Checking the Pump Motor
The purpose of this test is to check the proper
functioning of the peristaltic pump motor.
In the main menu, press <System Manager ->
Diagnostics>.
• Select the <Tests> tab.
•
Press <Pump> to start the test (Fig. 8-27).
• The pump will automatically step through all the
speeds used during normal operation (7.5 to 120
rpm (revolutions per minute)) (Fig. 8-28) and
return to the <Tests> screen.
Fig. 8-27 Pump Motor Test
Fig. 8-28 Pump Speed
