Operator’s Manual – OPTI CCA-TS2 3-13
3 CUSTOMIZATION
3.2.2.4 Setting up Limits for Measurement Parameters
This menu allows you to set up reference and critical
measurement limits for all measured parameters.
A result that is outside the limits you dene here
will be agged with a single up-arrow if above the
high reference limit, or a single down-arrow if below
the low reference limit. Results above or below the
critical limits will be agged with a double up-/or
down-arrow. A message is included on the printout
explaining each arrow.
NOTE: Whenthepatienttemperaturehasbeen
changed,boththeuncorrectedandcorrected
parameterswillbecheckedagainstthe
limitvaluesprogrammedhereandagged
accordingly.
1. In the main menu, select <System Manager>
and <Setup>.
2. On the <Patient/QC> tab, press
<Measurement Limits> (Fig. 3-25).
3. On the <Reference> tab (Fig. 3-26), select the
parameter you want to change and press
to
enter the new limit value. By default, reference
ranges are enabled.
4. Press to access pages 2 and 3 with the
remaining parameters (Fig. 3-27).
5. Press to accept the new limit value.
The instrument is preset to the following reference
ranges:
pH: 7.200 - 7.600
 PCO
2
: 30.0 - 50.0 mmHg
PO
2
: 70.0 - 700.0 mmHg
Na
+
: 135.0 - 145.0 mmol/L
K
+
: 3.50 - 5.10 mmol/L
Cl
-
: 95.0 - 115.0 mmol/L
Ca
++
: 1.13 - 1.32 mmol/L
Glu: 60.0 - 120.0 mg/dL
Glu: 3.3 - 6.6 mmol/L
BUN: 5.9 - 19.9 mg/dL
Urea: 2.1 - 7.1 mmol/L
Lac: 0.90 - 1.70 mmol/L
tHb: 12.0 - 17.0 g/dL
 SO
2
: 90.0 - 100.0 %
Fig. 3-25 Measurement Limits
Fig. 3-26 Reference Limits
Fig. 3-27 Enter Limits 2
