CAUTION
IF NECESSARY, CONTACT AN AUTHORISED SERVICE CENTRE.
03_18
Reverse (03_18, 03_19, 03_20, 03_21, 03_22, 03_23, 03_24)
The vehicle is equipped with a reverse system that facilitates manoeuvrability from a
standstill position.
The reverse gear allows a maximum speed on straight road of about 2 km / h (1.2
mph) and travelling a maximum gradient of approximately 18% only with the driver
and of approximately 15% with a passenger as well (of approximately 70 kg).
CAUTION
THE USE OF THE REVERSE GEAR MUST BE CONSIDERED EXCLUSIVE FOR
SHORT MANOEUVRES FROM A STANDSTILL POSITION. ANY OTHER TYPE OF
USE OTHER THAN THIS IS TO BE CONSIDERED IMPROPER, AND MAY CAUSE
THE BATTERY TO BE DAMAGED SOONER THAN NORMAL.
104
3 Use

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
