PIAGGIO MP3 530 hpe User Manual

• Complete the procedure within 5 minutes; if the ASR indicator light "2" stays
on steady, it means that the ASR procedure has failed.
Therefore, it is necessary to repeat the ASR calibration procedure until it is success-
fully completed.
Regarding the ASR indicator light after programming:
•
Procedure OK: ASR indicator light OFF and the system active. The next
time the ignition switch is turned "ON", the new wheel radius will be stored.
•
Procedure failed: The ASR indicator light STEADILY ON and the system
active (for safety purposes) with the previously memorized or the default
wheel radius (if it has never been programmed).
CAUTION
IF NECESSARY, CONTACT AN AUTHORISED SERVICE CENTRE.
N.B.
HOWEVER, THE SYSTEM CAN PERFORM AUTOMATIC CALIBRATION AFTER
TIRE REPLACEMENT.
02_108
The immobilizer system (02_108)
In order to enhance theft protection, the vehicle is equipped with a "PIAGGIO IMMO-
BILIZER" electronic engine locking device.
By pressing and releasing the starter switch, the "PIAGGIO IMMOBILIZER" system
will check the remote control.
Only if the protection system recognizes the remote control will it be possible to turn
the starter switch to "ON" to start the engine.
71
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
