PIAGGIO MP3 530 hpe User Manual

04_50
unscrew the stem «b» to remove it.
CAUTION
DO NOT ADJUST THE MIRRORS WHILE RIDING. THIS COULD CAUSE YOU TO
LOSE CONTROL OF THE VEHICLE.
04_51
04_52
Front and rear disc brake (04_51, 04_52)
Brake disc and pad wear are automatically compensated, and have no effect on the
function and performance of the brakes. Adjusting the brakes is therefore unneces-
sary. An excessively elastic brake lever stroke may indicate the presence of air in the
braking circuit or a failure in the braking system. In this case, especially considering
the fundamental role brakes play in your driving safety, it is necessary to take the
vehicle to an Authorised Service Centre or Dealer.
CAUTION
BRAKING SHOULD BEGIN AFTER ABOUT 1/3 OF THE BRAKE LEVER STROKE.
CAUTION
HAVE THE BRAKE PADS CHECKED BY THE DEALER ACCORDING TO THE
CHECKS SPECIFIED IN THE SCHEDULED MAINTENANCE TABLE. HOWEVER,
IN THE EVENT OF NOISES COMING FROM THE FRONT AND/OR REAR BRAK-
ING SYSTEM DURING OPERATION, IT IS ADVISABLE TO HAVE THE BRAKING
SYSTEM CHECKED BY AN AUTHORISED SERVICE CENTRE OR DEALER. AF-
154
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
