PIAGGIO MP3 530 hpe User Manual

02_109
Keys (02_109)
In addition to the remote control "A", the vehicle is also equipped with a "MASTER"
key "B".
The "MASTER" key is supplied in a single copy and is used to program other remote
controls and to open the saddle in an emergency (low battery).
To duplicate an additional remote control, contact the Authorised Service Centre,
equipped with the "MASTER" key and all the remote controls in possession.
WARNING
STORE THE MASTER KEY CAREFULLY.
LOSS OF IT IMPLIES THE REPLACEMENT OF ALL COMPONENTS OF THE
"PIAGGIO KEYLESS" SYSTEM.
02_110
Immobilizer device enabled indicator led (02_110, 02_111,
02_112)
The operation of the "PIAGGIO IMMOBILIZER" system is indicated by the flashing of
the specific indicator light.
After authentication and engine start-up, after about 50 meters running, the
presence of the remote control is checked; if the user no longer carries the
remote control, this will be indicated by flashing of the IMMOBILIZER light on
the instrument cluster.
However, this does not affect the operation of the vehicle.
72
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
