PIAGGIO MP3 530 hpe User Manual

damage), then refit the spark plug and turn the engine over slowly by a few revolutions
by pressing the starter button briefly;
4. Remove all fuel from the vehicle; spread anti-rust grease on the uncoated metal
parts; keep the wheels off the ground resting the frame on two wooden blocks;
5. As far as regards the battery, follow the instructions in paragraph «Battery».
04_55
Cleaning the vehicle (04_55, 04_56)
Use a low pressure jet of water to soften the caked dirt and mud deposited on the
painted surfaces. Once softened, sponge off mud and dirt using a car body sponge
soaked in a car body shampoo and water solution (2-4% of car shampoo in water).
Then rinse with abundant water, and dry with a chamois cloth.
WARNING
IN ORDER TO AVOID RISE OF OXIDATION, WASH THE VEHICLE EVERY TIME
IT IS USED IN AREAS OR SPECIAL CONDITIONS OF:
•
ENVIRONMENTAL / SEASONAL CONDITIONS: USE OF SALT, ANTI-ICE
CHEMICALS ON ROADS DURING WINTER.
•
AIR POLLUTION: CITIES AND/OR INDUSTRIAL AREAS.
•
SALINITY AND HUMIDITY: SEASHORE AREAS, HOT AND HUMID CLI-
MATE.
WARNING
•
PREVENT DEPOSITS FROM REMAINING ON THE BODYWORK, INDUS-
TRIAL AND POLLUTANT RESIDUAL DUST, TAR SPOTS, DEAD IN-
SECTS, BIRD DROPPINGS, ETC.
•
AVOID PARKING THE VEHICLE UNDER TREES. IN SOME SEASONS, IN
FACT, RESIDUES, RESINS, FRUITS OR LEAVES MAY FALL FROM THE
157
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
