THEREFORE, AN UNAUTHORISED PERSON COULD TURN THE SWITCH AND
EXIT THE ENGAGED STEERING LOCK POSITION (IF THE KNOB WAS SET TO
THE "LOCK" AND "OFF" POSITION), OR TURN THE KNOB TO "ON" (IF THE
KNOB WAS SET TO THE "OFF" AND "ON" POSITION).
02_75
Locking the steering wheel (02_75, 02_76)
Turn the handlebar to the left (end stop).
02_76
Turn the starter switch to the "LOCK" position.
CAUTION
DO NOT TURN THE SWITCH TO THE "LOCK" OR "OFF" POSITION WHILE RUN-
NING.
54
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
