PIAGGIO MP3 530 hpe User Manual

CAUTION
TO USE THE "INFLATE AND REPAIR" SPRAY CAN PROPERLY, FOLLOW THE
INSTRUCTIONS ON THE PACKAGING.
WARNING
THE WHEELS, COMPLETE WITH TYRES MUST ALWAYS BE BALANCED. RID-
ING THE VEHICLE WITH VERY LOW TYRE PRESSURE OR WITH INCORRECTLY
BALANCED TYRES CAN LEAD TO DANGEROUS STEERING VIBRATIONS.
CAUTION
WARNING
CARRY OUT THE DEFINITIVE REPAIRS AT AN AUTHORISED SERVICE CEN-
TRE.
04_54
Inactivity of the vehicle (04_54)
The following operations are recommended:
1. Clean the vehicle thoroughly and then cover it with a canvas;
2. Take care to place the vehicle on the centre stand, deactivating the front suspension
lock;
3. With the engine off and the piston at bottom dead centre, remove the spark plug,
add 1 to 2 cm³ of oil through the spark plug hole (larger quantities may cause engine
156
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
