PIAGGIO MP3 530 hpe User Manual

02_139
Extract the circuit from the lower half case and replace the battery.
Place the new battery with the positive pole (where the battery symbol is present)
facing the contact strips.
Refit the remote control carrying out the removal procedure in reverse order, by press-
ing the lower part and the two clip-on halves gently with your fingers.
02_140
USB port (02_140, 02_141)
Above the dashboard, inside the glove-box is a USB socket.
To use it, remove the protective cap. Cover the socket again with the cap to avoid that
water and/or humidity could damage it.
CAUTION
THE GLOVE BOX IS NOT WATERTIGHT.
DO NOT STORE OBJECTS THAT COULD BE AFFECTED BY HUMIDITY OR ANY
SUBSTANCES POURED ON THE BOX DOOR, EVEN WHEN CLOSED.
CAUTION
THE SUPPLIED USB PORT IS SUITABLE FOR RECHARGING AND/OR POWER-
ING MOST DEVICES CURRENTLY AVAILABLE ON THE MARKET.
85
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
