PIAGGIO MP3 530 hpe User Manual

02_143
The saddle (02_143)
In the helmet compartment there is a space for two full-face helmets, if correctly posi-
tioned as indicated in the figure:
02_144
Saddle opening. (02_144, 02_145, 02_146)
With the starter switch in "OFF" or "LOCK" position, it is possible to open the saddle
with the remote control pressing the button "3" for at least 1.5 seconds..
N.B.
THE REMOTE CONTROL CAN BE USED AT A DISTANCE LESS THAN 50 ME-
TERS FROM THE VEHICLE.
02_145
The saddle can also be opened electrically by pressing the corresponding button on
the handlebar, with the starter switch in the "OFF" or "LOCK" position.
With the starter switch in the "ON" position or with the engine running, the vehicle
must be at a standstill to open the saddle.
87
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
