TER REPLACING THE BRAKE PADS, DO NOT USE THE VEHICLE UNTIL YOU
HAVE OPERATED THE BRAKE LEVER SEVERAL TIMES IN ORDER TO ALLOW
THE PLUNGERS TO SETTLE AND THE LEVER STROKE TO BE SET TO THE
CORRECT POSITION.
CAUTION
THE PRESENCE OF SAND, MUD, SNOW MIXED WITH SALT, ETC. ON THE
ROAD, CAN DRASTICALLY REDUCE THE LIFE OF THE BRAKE PADS. IN OR-
DER TO AVOID THIS, WE RECOMMEND WASHING THE VEHICLE FREQUENTLY
WHEN RIDING IN THESE ROAD CONDITIONS.
04_53
Puncture (04_53)
The vehicle is equipped with Tubeless tyres (without inner tube). In the event of a
puncture, Tubeless tyres - unlike tyres with inner tubes - go flat very slowly, resulting
in a greater steering safety. In the event of a puncture, you can make an emergency
repair using an "inflate and repair" spray can. For a complete repair job contact an
Authorised Service Centre. Replacing a tyre means removing the wheel. For these
operations, contact an Authorised Service Centre.
WARNING
ALWAYS PERFORM THE CALIBRATION OF THE «ASR» SYSTEM AFTER A
PUNCTURE OR THE REPLACEMENT OF ONE OR MORE TIRES.
155
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
