02_82
With the D.R.L. daylight running lights on, the corresponding indicator lamp will light
up on the instrument cluster.
02_83
Light switch (02_83, 02_84)
The position "0" of the switch corresponds to the selection of the low beam light.
Lifting the switch to position "1" activates the high beam light.
The position «2» activates the high beam flashing; The switch returns automatically
to «0». The flashing control also releases the safety light function, can be activated in
case of failure of high beam light fuse.
N.B.
IN CASE OF LIGHTS SWITCH IN DAYLIGHT RUNNING LIGHT POSITION D.R.L.
ON, ONLY THE FLASHING OF THE HIGH BEAM LIGHT WILL BE POSSIBLE.
WARNING
DO NOT PLACE, TRANSPORT OBJECTS AND/OR CLOTHING ON THE LIGHT
CLUSTERS OR TURN INDICATORS SO AS NOT TO COVER THE LIGHT BEAM
OR TO AVOID DAMAGE TO THE VEHICLE.
57
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
