PIAGGIO MP3 530 hpe User Manual

02_77
Releasing the steering wheel (02_77)
Turn the starter switch to the "OFF" position.
CAUTION
DO NOT TURN THE SWITCH TO THE "LOCK" OR "OFF" POSITION WHILE RUN-
NING.
02_78
Switch direction indicators (02_78, 02_79)
Move the switch "A" to the left to position "1", to indicate a left turn; Move the switch
"A" to the right to position "2", to indicate a right turn. Press the switch "A" in the centre
to position «0» to deactivate the turn indicators.
02_79
When the turn indicators are activated, the corresponding indicator lamp will light up
on the instrument cluster, depending on the chosen direction.
55
2 Vehicle

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
