PIAGGIO MP3 530 hpe User Manual

04_25
The battery is the electrical device requiring the closest monitoring and most diligent
maintenance.
The main maintenance operations to be carried out are the following:
WARNING
UNDER NO CIRCUMSTANCES
MAY YOU
DISCONNECT THE BATTERY LEADS WHILE THE ENGINE IS RUNNING; THIS
CAN CAUSE IRREPARABLE DAMAGE TO THE VEHICLE'S ELECTRONIC CON-
TROL UNIT.
WARNING
USED BATTERIES ARE HARMFUL TO THE ENVIRONMENT. COLLECTION AND
DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH REGULATIONS
IN FORCE.
04_26
Use of a new battery (04_26, 04_27, 04_28, 04_29)
To remove the empty battery, proceed as follows:
access the battery as described in the section "Battery".
Unscrew the screw of the negative terminal "-".
137
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
