PIAGGIO MP3 530 hpe User Manual

WARNING
TO AVOID THE RISK OF SCALDING, DO NOT UNSCREW THE EXPANSION
TANK COVER WHILE THE ENGINE IS STILL HOT.
WARNING
YOU MUST MAKE SURE THE FLUID NEVER EXCEEDS THE MAXIMUM LEVEL
INDICATED SO AS TO AVOID IT OVERFLOWING AND CAUSING DAMAGE
WHILE THE SCOOTER IS MOVING.
TO ENSURE CORRECT ENGINE OPERATION, KEEP THE RADIATOR GRILLE
CLEAN.
04_17
Checking the brake oil level (04_17, 04_18, 04_19, 04_20, 04_21)
Both front and rear brake fluid tanks are equipped with a transparent visual indicator
«A»; the quantity of fluid contained indicates the fluid level in the relative tank.
To control the brake fluid level, do the following:
- Place the bike on the centre stand with the handlebar pointing straight;
-check the liquid level through the related inspection windows «A»:
•
if the window is full, the brake fluid is correct.
•
If the brake fluid level approaches the «MIN» reference, contact an Author-
ised Service Centre for the corresponding checks.
•
If the brake fluid level is below the «MIN» reference, do not use the vehicle
and contact an Authorised Service Centre.
133
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
