PIAGGIO MP3 530 hpe User Manual

CAUTION
FOR OIL REPLACEMENT, CONTACT ANY AUTHORISED SERVICE CENTRE AS
THEY ARE EQUIPPED TO DISPOSE OF USED OILS IN AN ENVIRONMENTALLY
FRIENDLY AND LEGAL WAY.
04_08
TOP-UP
If necessary carry out the top-up, DO NOT use the vehicle and contact an Author-
ised Service Centre.
04_09
Tyres (04_09)
Regularly check (about every 500 km) the pressure and wear of the tyres. Tyres fea-
ture wear indicators; replace tyres as soon as these indicators become visible on the
tyre tread. Also, check that the tyres do not have cuts on the sides or an irregular tyre
tread wear; if this occurs contact an Authorised Service Centre.
CAUTION
FOR THE REPLACEMENT OF THE TYRES CONTACT AN AUTHORISED SERV-
ICE CENTRE.
128
4 Maintenance

PIAGGIO MP3 530 hpe Specifications

General

Displacement	530 cc
Fuel System	Electronic fuel injection
Transmission	CVT with torque server
Rear Brake	240 mm disc
ABS	Yes
Tire Size Front	110/70 - 13"
Tire Size Rear	140/70 - 14"
Width	800 mm
Seat Height	790 mm
Weight	280 kg
Engine Type	4-stroke, single-cylinder
Max Power	32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque	50 Nm at 5, 250 rpm
Cooling System	Liquid cooled
Front Suspension	Articulated quadrilateral
Front Brakes	Two 258 mm discs
Rear Suspension	Double shock absorber with adjustable preload
