CAUTION
DO NOT REVERSE THE POLARITY: RISK OF SHORT CIRCUIT AND DAMAGE
TO THE ELECTRICAL SYSTEM.
04_30
Long periods of inactivity (04_30)
If the vehicle is not used for a long time, the performance of the battery will deteriorate.
This is the result of the natural phenomenon of battery discharging, and may be due
to residual absorption by vehicle components with constant power consumption. The
deterioration of the battery's performance is also the result of environmental conditions
and how clean the terminals are. To avoid any starting difficulties and/or irreparable
damage to the battery, you should do the following:
- At least once a month start up the engine and turn it over at a speed slightly above
idling, for 10-15 minutes. This will enable you to keep all the parts of the engine in
working order as well as the battery.
- Take your vehicle to a garage (as indicated in the "Vehicle not used for extended
periods" section) to have the battery removed. The battery must be cleaned, fully
charged and kept in a dry, well aerated place. Charge the battery again at least every
two months.
CAUTION
BATTERY CHARGING MUST BE DONE WITH A CURRENT EQUAL TO 1/10 THE
RATED CAPACITY OF THE BATTERY ITSELF FOR NOT MORE THAN 8 HOURS.
IN ANY CASE, IT IS PREFERABLE TO PERFORM THIS SERVICE AT AN AU-
THORISED SERVICE CENTRE. WHEN REFITTING THE BATTERY MAKE SURE
THE LEADS ARE CORRECTLY CONNECTED TO THE TERMINALS.
139
4 Maintenance

Table of Contents

Other manuals for PIAGGIO MP3 530 hpe

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PIAGGIO MP3 530 hpe and is the answer not in the manual?

PIAGGIO MP3 530 hpe Specifications

General IconGeneral
Displacement530 cc
Fuel SystemElectronic fuel injection
TransmissionCVT with torque server
Rear Brake240 mm disc
ABSYes
Tire Size Front110/70 - 13"
Tire Size Rear140/70 - 14"
Width800 mm
Seat Height790 mm
Weight280 kg
Engine Type4-stroke, single-cylinder
Max Power32.5 kW (44.2 HP) @ 7, 250 rpm
Max Torque50 Nm at 5, 250 rpm
Cooling SystemLiquid cooled
Front SuspensionArticulated quadrilateral
Front BrakesTwo 258 mm discs
Rear SuspensionDouble shock absorber with adjustable preload
