Hunter-Pro Series Captain 8 - Installation Guide
46
The wireless zones are numbered only after all other zones, including the
hardwired expanders' zones.
The number of wireless zones & peripherals varies according to the system
model. See the table on page 30.
Deleting a wireless zone
Setting the wireless zones' supervision interval
4.2.3. Keypads setup
Set the number of monitored (addressable) keypads (up to 8). The system supervises every
keypad that carries an ID other than zero (1-8). The IDs should be set consecutively, from #1.
If monitoring the keypads is not required, the number of keypads should be
left zero.
Keypads partitioning
When partitions are in use, each keypad control some or all the partitions. Up to 16 partitions can
be set in the Hunter-Pro series, 4 in Captain 8.
While viewing the partitions screens, the 16 numerals printed below the LCD screen serve as the
partitions’ numbers.
To set the partitions of the keypad:
1. Enter a keypad number or scroll using [NEXT] and [BACK].
2. Set to ‘+’ the partitions that this keypad will control. In the following examples, keypad #3
controls partitions 1-2, 5-8, 14-16 in the Hunter-Pro, and 1-2 in Captain 8.
4. Press [ENTR] to save and set the next keypad, or press [END] to exit.
4.2.4. I/O-R expander settings
Set the number of I/O-R relay expanders. Each expander has 8 relay outputs.
The I/O-R cannot be connected to Captain 8
ENTR
1
Wireless Setup
ENTER/NEXT/END
ENTRNEXT
X2
Delete Zone?
ENTER/NEXT/END
ENTR
NEXT
Delete Zone? 9
Please Wait...
. . . .
Device Deleted
Press END
Enter zone
number
Add Zone?
ENTER/NEXT/END
Supervision:
ENTER/NEXT/END
Supervision:
Hrs:12 Min.s:0
ENTR
1
ENTRNEXT
X2
ENTR
BACK
KPD 3 partitions
++--++++-----+++
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
KPD 3 partitions
++--
1 2 3 4
Hunter-Pro Captain 8
