Pima Captain 8 Installation Guide

Hunter-Pro Series Captain 8 - Installation Guide
8
1 Hunter-Pro Series
The Hunter-Pro Series has two models: 832 for 8-32 zones, and 8144 for 8-144 zones.
Both models are hybrid (can use both hardwired and wireless zones, using a wireless expander).
The Hunter-Pro Series offers complete panel integration with full data channels, such as GSM-
GPRS, SMS, TCP/IP, PSTN and long-range radio.
1.1. Main features
 Hybrid system with expandable 32/144 zones, 24/32 of which could be wireless
1
 Up to 16 partitions
 Up to 8 monitored keypads
 Supports PIMAlink 2.0 cloud application
 Onboard zone doubling
 SMS notifications (using the SMS-100 or GSM-200 modules)
 Full remote control over PSTN, including the outputs
 Wireless detectors supervision
 Comprehensive zone tests
 Communication channels: PSTN, Radio, GSM/GPRS and Ethernet
 Supports split and double reporting
 Burglary setup prevention measures
 Continuous battery and telephone line tests
 Swinger shutdown
1.2. The control panel
Diagram 1. The Hunter-Pro Series PCB
1
Requires the I/O-WN receiver
21
22
1 3 4 5 6 72 108 9
11
12
13
2
14
15161718
19
20
1 2
