9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
6.9
PVT ASSEMBLY
1. Install the inner clutch cover in the vehicle.
2. Install the seven fasteners retaining the inner clutch
cover to the engine and transmission. Torque to
specification.
TORQUE
Inner Clutch Cover Fasteners:
10 ft-lb (14 Nm)
3. Install the Drive Clutch. Torque mounting bolt to
specification.
TORQUE
Drive Clutch Bolt:
96 ft-lb (130 Nm)
4. Install the Driven Clutch. Torque mounting bolt to
specification.
TORQUE
Driven Clutch Bolt:
55 ft-lb (75 Nm)
5. Install the drive belt.
6. Install the PVT intake and exhaust ducts to the inner
clutch cover. Torque clamps to specification.
TORQUE
Duct Clamps:
12 ft-lb (16 Nm)
7. Install the eight screws retaining the outer clutch
cover. Torque screws to specification.
TORQUE
Outer Clutch Cover Screws:
54 in-lb (5 Nm)
8. Install second intake hose onto PVT cover and tighten
hose clamp until taught.
PVT SYSTEM
