12
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
12.21
CHARGING SYSTEM
STATOR
Refer to Engine Chapter – Stator Cover Removal /
Inspection page 3.47 to service the stator.
NOTICE
The stator cover can be removed with the engine
installed in the chassis.
Be sure to thoroughly clean the area around the stator
cover prior to removal.
VOLTAGE REGULATOR
The regulator / rectifier
q
is located in front of the
radiator.
NOTICE
If the regulator / rectifier case temperature exceeds
230° F or 110° C, the unit will turn itself off to cool down.
The unit will turn on again after it has cooled down to at
least 212° F or 100° C. If it turns off, verify the cooling
fins are clean, free from debris and that adequate
airflow is present.
ELECTRICAL
To Next Page
