Printer Engine Service Mode
Service Mode Table
Notation What it means
[range/default/step]
Example: [-9 to +9/+3.0/0.1 mm step]. The setting can be adjusted in
the range ±9, value reset to +3.0 after an NVRAM reset, and the value
can be changed in 0.1 mm steps with each key press.
DFU Denotes "Design or Factory Use". Do not change this value.
SP1-xxx: Feed
1001
Lead Edge Regist Leading Edge Registration
Adjusts the printing leading edge registration for feeding from the trays and duplex tray
using the trimming area pattern (SP5-902-003 No.9).
Push [] or [] to select the settings (plus or minus).
The specification is 4±2 mm
1001 001 Bypass Tray Plain
[-40 to +40/0/1]
1001 002 Bypass Tray Thick
1001 003 Main Tray Plain
1001 004 Main Tray Thick
1001 005 Optional Tray
1001 006 Duplex
1002
Side to Side Reg Side-to-Side Registration
Adjusts the printing side-to-side registration from the 1st paper feed station using the
trimming area pattern (SP2-902 No.12).
Push [] or [] to select the settings (plus or minus).
Specification: 0 ±2.0 mm.
1002 001 1st Tray
[-40 to +40/0/1]
Printer Engine Service Mode
87
