Roland FANTOM-06 Reference Manual

Playing the Sequencer
115115
Playing Song
1. Select a scene.
Select a scene in which a song is created.
Scenes in which a song is created have a “SONG” indication
as shown in the illustration.
2. Press the [SONG] button.
The SONG screen appears.
Current group box
Empty group box
A succession of boxes called group boxes is shown, each
with a number indicating the playback order.
Within each group box is shown information such as the
group number, group name, and the number of times it will
loop.
Nothing is shown in an empty group box.
Number of loops
Group number
Simplied indication of
playback position
Group name
3. Press the [øPLAY] button.
The song plays, and the groups play in numerical order.
The currently-playing group (the current group) is indicated
by a green group box.
4. Press the [ðSTOP] button to stop playback.
Showing the Timeline as Measures
(MEAS)
Numbers that indicate the playback order are shown above the
group box in the screen, but you can switch these to indications of
the measure. Viewing the timeline in terms of measures can make
the structure of the song easier to understand.
1. In the SONG screen, select [E5] MEAS.
The indication above the boxes changes to a measure
indication.
Measure indication

Roland FANTOM-06 Specifications

General

Bit rate	24 bit
Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Chorus, Reverberation
Sound effects quantity	16
Chorus effects quantity	9
Keyboard number of keys	61
Preset programs quantity	10
Maximum polyphony (notes)	8
Reverberation effects quantity	7
6.35 mm (1⁄4-inch) input	1
Display type	LED
Power source type	AC

Weight and Dimensions

Depth	323 mm
Width	1006 mm
Height	95 mm
Weight	6000 g
