Settings for the Entire FANTOM
167167
Parameter Value Explanation
S1, S2 Switch
Mode
Specify the behavior of the buttons.
MOMENTARY
The assigned eect is applied only
while you hold down the button.
LATCH
The eect is switched each time you
press the button.
Slider Settings
(SLIDER)
Parameter Value Explanation
Slider Mode
DIRECT,
CATCH
Species whether control data of
the corresponding position is always
output when you move a slider
(DIRECT) or control data is output
only after the slider position passes
through the current value of the
parameter (CATCH).
Assignable
Slider1–8
Assign
Assigns the function controlled by the sliders.
OFF No function is assigned.
CC01–31,
33–95
Controller number 1–31, 33–95
BEND
The same eect as moving the pitch
bend lever.
AFT Aftertouch
Slider1–8
Range Min
0–127
Specify the lower limit value for the
range of the assigned function.
Slider1–8
Range Max
0–127
Specify the upper limit value for the
range of the assigned function.
Knob Settings
(KNOB)
Parameter Value Explanation
Knob Mode
DIRECT,
CATCH
Sets whether the knobs always output
their control data corresponding to
their current position (DIRECT), or
whether they only output control
data when their position passes the
parameter’s value (CATCH).
Assignable
Knob1–8
Assign
Assigns the function controlled by the control knobs.
OFF No function is assigned.
CC01–31,
33–95
Controller number 1–31, 33–95
BEND
The same eect as moving the pitch
bend lever.
AFT Aftertouch
Knob1–8
Range Min
0–127
Specify the lower limit value for the
range of the assigned function.
Knob1–8
Range Max
0–127
Specify the upper limit value for the
range of the assigned function.
USB Audio Settings
(USB AUDIO)
Parameter Value Explanation
USB Audio
Mix/Parallel
MIX
All audio signals output from the
FANTOM are mixed to channels 1–2.
This is convenient for stereo recording.
Other channels are output according
to their settings.
PARALLEL
The audio signals output from the
FANTOM are output individually from
all channels. This is convenient for
simultaneous multi-channel recording.
Input
USB Audio
Input Switch
OFF, ON
Species whether audio from a
computer or other device connected
to the USB COMPUTER port is input to
the FANTOM (ON) or is not input (OFF).
USB Audio
Input Level
0–127 Adjusts the USB audio input level.
Output
USB Audio
Output
Switch
OFF, ON
Species whether audio from the
FANTOM is output to a computer or
other device connected to the USB
COMPUTER port (ON) or is not output
(OFF).
USB Audio
Output Level
0–127 Adjusts the USB audio output level.
MIDI Settings
(MIDI)
Parameter Value Explanation
Device ID 17–32
When transmitting and receiving
system exclusive messages, the device
ID numbers of both devices must
match.
Scene Control
Channel
1–16, OFF
Species the MIDI channel for
controlling the scene.
USB-MIDI
Thru
OFF, ON
Species whether MIDI messages
received via the USB COMPUTER
port/MIDI IN connector will be
re-transmitted from the MIDI OUT
connector/USB COMPUTER port (ON)
or not be re-transmitted (OFF).
Remote
Keyboard
Switch
OFF, ON
Turn this “ON” if you are using an
external MIDI keyboard instead of the
FANTOM’s keyboard. In this case, the
MIDI transmit channel of the external
MIDI keyboard does not matter.
Normally you will leave this “OFF”.
* Turn this “ON” if you’re using an
external MIDI device to control
arpeggio performance.
Transmit
Transmit
Program
Change
OFF, ON
Sets whether to transmit a program
change message (ON) or not (OFF)
when you switch the scene or tone.
Transmit Bank
Select
OFF, ON
Sets whether to transmit a bank select
message (ON) or not (OFF) when you
switch the scene or tone.
Transmit
Active
Sensing
OFF, ON
Species whether active sensing
messages will be transmitted (ON) or
not be transmitted (OFF).
Transmit Edit
Data
OFF, ON
Species whether changes in the
scene settings are transmitted as
system exclusive messages (ON) or not
transmitted (OFF).
