Roland FANTOM-06 Reference Manual

Convenient Functions (Utility)
155155
Menu Explanation
[E1] Scrolls the screen up/down.
[E2] CLEAR ALL Clears all of the check boxes.
[E3] SELECT ALL Selects all of the check boxes.
[E4] PREVIEW
Previews the sample selected by the
cursor.
[E6] NEXT Moves to the next operation.
Touch a check box
while holding the
[SHIFT] button
Selects the check boxes for multiple
samples all at once, from the sample at the
cursor position to the sample you touch
while holding down the [SHIFT] button.
10. Select [E6] NEXT.
The IMPORT SAMPLE (SELECT DESTINATION) screen appears.
This is a list of samples in the FANTOM.
Number marked / Number of samples
11. Touch the check box to the left of a sample to
select it as the import destination.
NOTE
The selected sample at the import destination is overwritten.
The check boxes are automatically selected by default, so that
INITIAL SAMPLE is the import destination.
12. Select [E6] EXECUTE.
A conrmation message appears.
If you decide to cancel, select [E6] CANCEL.
13. Select [E5] OK.
The sample is imported, and the unit returns to the IMPORT
MENU screen.
Exporting Tone Data
(EXPORT)
Here’s how the FANTOM’s sound data (tone/drum) can be exported
to a USB ash drive as a .svz format le.
MEMO
¹
The exported data can also be loaded by another sound
module that supports ZEN-Core tones (such as the Jupiter-
Xm).
¹
VTW or SuperNATURAL sounds cannot be exported.
1. Insert the USB ash drive into the FANTOM’s USB
MEMORY connector.
2. Press the [MENU] button.
The MENU screen appears.
3. Touch <UTILITY>.
The UTILITY screen appears.
4. Touch <EXPORT>.
5. Touch <EXPORT TONE>.
The EXPORT TONE (SELECT SOURCE) screen appears.
Number marked / Number of items
Tones already imported
Tones used in a scene
MEMO
To export a drum tone, touch <EXPORT DRUM>.
6. Touch the box at the left of the tone(s) that you
want to export, adding a check mark.
Menu Explanation
[E1] Scrolls the cursor up or down.
[E2] CLEAR ALL Clears all check marks.
[E3] SELECT ALL Adds a check mark to all tones.
[E6] NEXT Proceeds to the next step.
Hold down the
[SHIFT] button and
touch a check box
Adds a check mark to multiple tones in
a single action, starting from the tone at
the cursor location to the tone that you
touched while holding down the [SHIFT]
button.
7. Select [E6] NEXT.
The EXPORT TONE (SELECT DESTINATION) screen appears.
Menu Explanation
[E1]
Scrolls the screen up/down to select the
save-destination.
[E2] RENAME Edits the name of the le that is exported.
[E6] EXECUTE Executes the export.
8. Use the [E1] knob to select the save-destination
folder.

Roland FANTOM-06 Specifications

General

Bit rate	24 bit
Pitch wheel	Yes
Product type	Digital synthesizer
Product color	Black
Sound effects	Chorus, Reverberation
Sound effects quantity	16
Chorus effects quantity	9
Keyboard number of keys	61
Preset programs quantity	10
Maximum polyphony (notes)	8
Reverberation effects quantity	7
6.35 mm (1⁄4-inch) input	1
Display type	LED
Power source type	AC

Weight and Dimensions

Depth	323 mm
Width	1006 mm
Height	95 mm
Weight	6000 g
