Product type DL1000 and DT1000
Housing material Aluminum alloy
Glass
Polycarbonate
PA
Connection type M12 round connector x 1
Display Graphical, resistive touch display, status LEDs
Weight 980 g
Enclosure rating IP 65, IP 67 (IEC 60529)
3
Protection class III (EN 61140)
Electrical safety EN 61010
1
May not fall short of or exceed U
V
tolerances
2
With external load
3
Plugged in with suitable mating connector
11.4 Ambient data
Product type DL1000 and DT1000
Ambient temperature Operation: –40 °C ... +55 °C
1
Storage: –40 °C ... +75 °C
Max. rel. air humidity (non-
condensing)
≤ 95%
Effect of air pressure 0.3 ppm/hPa
Effect of temperature -1 ppm/K
Temperature drift Typ. 0.25 mm/K
Mechanical stability Shock: 30 g / 6 ms according to DIN EN 60068-2-27 (Ea), 6 axes
Continuous shock: 25 g / 6 ms according to DIN EN 60068-2-27
(fatigue), 500 shocks, 6 axes
Sine-wave vibration: 10 Hz ... 500 Hz, 1 g according to
DIN EN 60068-2-6
Altitude < 5,000 m above sea level
Ambient conditions Degree of contamination 3 (according to EN 61010-1)
2
1
At a temperature of -40 °C, a warm-up time of typ. 20 minutes is required (when supply voltage Uv =
24 V)
2
Valid for device environment
11.5 Classifications
Product type DL1000 and DT1000
ECl@ss 5.0 27270801
ECl@ss 5.1.4 27270801
ECl@ss 6.0 27270801
ECl@ss 6.2 27270801
ECl@ss 7.0 27270801
ECl@ss 8.0 27270801
ECl@ss 8.1 27270801
ECl@ss 9.0 27270801
ETIM 5.0 EC001825
ETIM 6.0 EC001825
11 TECHNICAL DATA
104
O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000 8019329/12TZ/2019-03-28 | SICK
Subject to change without notice
