SICK DT1000 User Manual

Parameter Factory setting
4k8:
4800 baud
115k2
9k6:
9600 baud
19k2:
19200 baud
38k4:
38400 baud
57k6:
57600 baud
115k2:
115200 baud
230k4:
230,400 Baud
8.5.3 Defining the RS-422 data format
Define the data output format of the RS-422 interface.
Parameter Factory setting
8n1:
8 data bits, no parity, 1 stop bit
8n1
8o1:
8 data bits, odd parity, 1 stop bit
8e1:
8 data bits, even parity, 1 stop bit
7n1:
7 data bits, no parity, 1 stop bit
7o1:
7 data bits, odd parity, 1 stop bit
7e1:
7 data bits, even parity, 1 stop bit
8.5.4 Setting the continuous RS-422 output
Select the type of data output using the RS-422 interface.
8 REFERENCE
72
O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000 8019329/12TZ/2019-03-28 | SICK
Subject to change without notice
