11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/Dx1000
11.1 Performance
Product type DL1000 DT1000
Measuring range 0.2 m ... 1,500 m
1
,
2
,
3
, see "Mea‐
suring range diagrams",
page 97
0.2 m ... 460 m
1
,
4
,
5
, see "Mea‐
suring range diagrams",
page 97
Resolution 0.001 mm ... 100 mm, adjustable
6
Reproducibility 1 mm ... 15 mm
1
,
2
,
7
,
10
, see
"Repeatability diagrams",
page 99
1 mm ... 15 mm
1
,
5
,
7
,
10
, see
"Repeatability diagrams",
page 99
Accuracy (distance)
8
<± 20 mm (at 0.2 m ... 5 m)
<± 10 mm (at 5 m ... 50 m)
<± 20 mm (at 50 m ... 100 m)
<± 22 mm (at 200 m)
9
<± 48 mm (at 1500 m)
<± 10 mm (at 0.2 m ... 50 m)
<± 20 mm (at 50 m ... 100 m)
<± 24 mm (at 100 m ... 200 m)
Accuracy (speed)
10
Typically ± 10 mm/s
Response time 3 ms ... 384 ms
11
Measurement cycle
time
1 ms, 4 ms, 16 ms 1 ms, 4 ms, 16 ms, 64 ms,
128 ms
Max. axial traversing
speed
128 m/s (at 1 ms measurement
cycle time)
32 m/s (at 4 ms measurement
cycle time)
8 m/s (at 16 ms measurement
cycle time)
128 m/s (at 1 ms measurement
cycle time)
128 m/s (at 1 ms measurement
cycle time)
128 m/s (at 1 ms measurement
cycle time)
2 m/s (at 64 ms measurement
cycle time)
1 m/s (at 128 ms measurement
cycle time)
Max. acceleration 150 m/s
2
150 m/s
2
(at 1, 4 or 16 ms mea‐
surement cycle time)
31.3 m/s
2
(at 64 ms measure‐
ment cycle time)
7.8 m/s
2
(at 128 ms measure‐
ment cycle time)
Light sender Measurement laser, infrared (invisible, wavelength 905 nm, max. out‐
put power ≤ 21 W, pulse length 2.5 ns)
Alignment laser, red (visible, wavelength 650 nm, max. output power
≤ 390 μW, pulse length 50 ms)
Laser class 1 (EN 60825-1, even with simultaneous operation of measurement
and alignment laser)
TECHNICAL DATA 11
