3. Remove additional filter upwards:
5.5 Placement of multiple distance sensors
For the DL1000, no particular requirements have to be upheld concerning a minimum
distance.
For the DT1000, observe the following information on minimum distances.
Light beams in the same direction
s
m
a
x
.
a
1
2
1
2
3
4
1
2
3
4
1
2
Figure 10: Placement of two DT1000 units with light beams in the same direction
1
DT1000
2
Measuring object (natural object)
a Minimum distance
s
max
Maximum measurement distance
5 MOUNTING
36
O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000 8019329/12TZ/2019-03-28 | SICK
Subject to change without notice
