Expansions and parameter assignment
10.4 Drive racks and storage media
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
89
Removing an SSD from the HDD carrier
How to install the SSD
1. Remove the HDD carrier (1) as
described in section 5Removing and
inserting the HDD carrier
(Page 282).
1
2. Turn the HDD carrier upside down
and loosen the indicated screws on
the bottom of the HDD carrier with
a Torx T10 screwdriver.
The SSD is removed from the HDD carrier.
Installing an SSD in the HDD carrier
Perform the tasks describe above in reverse order.
