Siemens SIMATIC TDC User Manual

Signal modules
5.1 SM500 signal module
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
107
5.1.6
Additional components
Table 5- 3 Cables and interface modules for signal module SM500
Component
Designation
Article number
Cable for SM500
(50-pole/5*10-pole)
SC62 6DD1684-0GC0
Cable for digital inputs (50-pole/50-pole) SC63 6DD1684-0GD0
Interface module
Direct wiring (1:1 wiring), 10 screw terminals, no
signal conversion
SU12 6DD1681-0AJ1
Interface module
Direct wiring (1:1 wiring), 50 screw terminals, no
signal conversion
SU13 6DD1681-0GK0
Interface module
Direct wiring (1:1 wiring), 8 digital I/O, LED, no signal
conversion
SB10 6DD1681-0AE2
Interface module
8 digital inputs, conversion, 120 V to 24 V (module
signal level), LED, electrical isolation
SB60 6DD1681-0AF4
Interface module
8 digital inputs, conversion 48 V to 24 V, LED, elec-
trical isolation
SB61 6DD1681-0EB3
Interface module
8 digital outputs, conversion, 24 V to 120 V (change-
over relay), LED, electrical isolation
SB70 6DD1681-0AG2
Interface module
8 digital outputs, conversion 25 V to 48 V (transistor)
SB71 6DD1681-0DH1
