Interface module
7.6 Interface modules SU12 und SU13
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
211
Interface modules SU12 und SU13
Article number
SU126DD1681-0AJ1
SU136DD1681-0GK0
Interface module SU12 is a
terminal block that is used to wire the
analog or digital signals of a
ribbon cable connector (SIMATIC side) to
cage clamp terminals (plant side).
Interface module SU13 is a
terminal block that is used to wire 50 sig-
nals routed via a 50-pole connector (SIMATIC
side) to screw terminals (plant side).
16 spring-loaded terminals (X2)
10 spring-loaded terminals for analog or digital signals on plant side
6 unused spring-loaded terminals
50 screw terminals (X2)
Connection of 50 signals
