Interface module
7.6 Interface modules SU12 und SU13
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
213
Additional components
Cables for:
The following cables are required to wire the interface modules to the modules:
Table 7- 8 Modules and signal cables as additional components for SU12
SC66 CPU551 X2
Table 7- 9 Modules and signal cables as additional components for SU13
CP52M0 X6
The interface modules are suitable for
mounting positions. The
modules must be installed on mounting rails.
For more information on EMC and environmental conditions, refer to section "General
technical specifications (Page 37)"
