SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
121
Communication modules
6
6.1
CP50M1 communication module
6.1.1
Areas of application
CP50M1 is a communication module with communication memory function and two
PROFIBUS DP interfaces (MPI interface only on X1).
Use cases include:
● Interfacing with distributed I/O devices and/or drives (master and/or slave function)
● Central commissioning of all CPU modules in the rack (MPI nodes)
● Buffer memory for data exchange between CPU modules
● Function for routing to other CP modules
● Connection of SIMATIC visualization components, e.g.: WinCC, or OP/TD
Replacing a CP50M0 with a CP50M1
Note
Replaceent parts compatibility
The CP50M1 is not compatible with CP50M0 as a replacement part.
If a CP50M0 is
replaced by a CP50M1, it must be re-configured in HW Config.
CP50M0
CP50M1
Article number
6DD1661-0AD0
6DD1661-0AD1
PROFIBUS DP interface (X1 / X2)
2
(X1 + X2 optionally DP or
MPI)
2
(X1 optionally DP or
MPI)
MPI interface
2
1
Parameter assignment and diagnostics inter-
face
yes yes
Function for routing to other CP modules
no
yes
Communication memory
----
SDRAM, 1MB
Buffer memory module
DRAM, 8 MB
SDRAM, 8 MB
VMEbus configuration memory
----
NOR Flash, 512 KB
