Siemens SIMATIC TDC User Manual

Interface module
7.1 Interface module SB10
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
179
7.1.3
Technical specifications
General data
Mounting system
Suitable for snap-on mounting on rails
Dimensions W x H x D [mm]
45 x 129 x 160 mm
Weight
Approx. 0.28 kg
Ambient temperatures
Ambient temperatures
max. 60°°C
Power supply
Description
SIMATIC TDC
Supply voltage (V
V
) at rated value
24 V DC
Valid range 20.4 V to 28.8 V DC
Briefly t<500 ms
1.5 x V
rated
Current consumption
At rated value
1)
20 mA
Maximum current per supply line
400 mA
1)
LED intrinsic consumption without load on system modules
The maximum current of 1 A may not be exceeded on connector X3 if the supply of several
terminal blocks is routed via this connector.
Digital signals
Number
8
Rated voltage
24 V DC
Maximum current per channel
30 mA
