Page #180 background image
Interface module
7.1 Interface module SB10
SIMATIC TDC hardware
180 System Manual, 08/2017, A5E01114865-AL
7.1.4
Pin assignment
Ribbon cable connector X1
The cables SC62 or SC66 are used to connect the interface modules to the SIMATIC TDC
components (for more information, refer to the SIMATIC TDC Documentation).
Terminal block X2
Table 7- 1 Pin assignment of the digital I/O of interface module SB10
Terminal
Designation
1
2
3
4
5
6
7
8
Channel 1 (digital input/output 1)
Channel 2 (digital input/output 2)
Channel 3 (digital input/output 3)
Channel 4 (digital input/output 4)
Channel 5 (digital input/output 5)
Channel 6 (digital input/output 6)
Channel 7 (digital input/output 7)
Channel 8 (digital input/output 8)
51
52
53
54
55
56
57
58
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Reference busbar, 1M (1P can be set)
Conductor cross-section
The minimum conductor cross-section for the terminal block X1 is 0.2mm² and the maximum
is 2.5 mm².
