Communication modules
6.1 CP50M1 communication module
SIMATIC TDC hardware
126 System Manual, 08/2017, A5E01114865-AL
Additional components
Examples for PROFIBUS RS485 bus connector
● 6ES7972-0BA12-0XA0 (90°; without PG socket)
● 6ES7972-0BA12-0XA0 (90°; without PG socket)
● 6ES7972-0BA42-0XA0 (35°; without PG socket)
● 6ES7972-0BB42-0XA0 (35°; without PG socket)
● 6ES7972-0BA30-0XA0 (30°; without PG socket)
Examples for fabricated cables (RS485)
● 6XV1830-1CH15 (1.5 m)
● 6XV1830-1CH30 (3 m)
● 6XV1830-2AH30 (3 m; PG)
● 6XV1830-2AH50 (5 m; PG)
● 6XV1830-2AN10 (10 m; PG)
can find more information in the SIMATIC NET Catalog IK PI or in the SIMATIC S7
