Communication modules
6.5 CP52A0 GDM access module
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
159
Status and fault displays
Status displays for CP52A0
Table 6- 19 Status displays for the CP52A0 GDM access modules
FPGAs are configured, module is not initialized
On Off Module is initialized and operating error-free
On On After 3.3 V or 2.5 V voltage failure
• Hardware failure => Switch off the rack and replace CP52A0
Status displays for communication
Table 6- 20 Status and fault displays of the CP52A0 GDM access module
H3
No data transmission to the CP52IO GDM interface module
*)
Data transmission to the CP52IO GDM interface module
H4 Off Missing or faulty data transmission from the CP52IO GDM interface mod-
*)
Error-free data transmission from the CP52IO GDM interface module
H5
No ramp-up ID from the CP52IO GDM interface module
H6 Off Clock trigger and base sampling time are parameterized and have send
authorization from CP52IO
On The clock trigger and basic sampling time have been parameterized for
transmission but have no transmit authorization from the CP52IO (priority
logic is inhibiting one of the two signals)
*)
The brightness of the LED indicates the density of periodic data traffic.
