Siemens SIMATIC TDC User Manual

Rack
3.3 Rack UR5213 (6DD1682-0CH0)
SIMATIC TDC hardware
System Manual, 08/2017, A5E01114865-AL
73
3.3.9
Technical specifications
Article number
Rack UR5213
6DD1682-0CH0
General data
Safety EN 61131-2
Degree of protection
IP 20
Protection class
Protection class 1 with PE/ground conductor
Storage temperatures
-40 °C to +70 °C
Operating temperatures
0 °C to +55 °C
Relative air humidity
5 % to 95 %, no condensation
Atmospheric pressure Operation: 1080 hPa to 795 hPa
Storage: 1080 hPa to 660 hPa
Power input
Input voltages (AC)
90 V - 264 V
Rated input current
Typically < 10 A
Max. inrush current
< < 50 A
Frequency
47 Hz to 63 Hz
Power factor
EN 61000-3-2
Power failure backup
min. 15 ms
Output voltages
Rated output voltage
Output current
+5 V
60 A
+3.3 V
60 A
+12 V
8 A
-12 V
8 A
All outputs are sustained short circuit-proof and
do not
need a basic load.
Battery
Current load
approx. 10 µA for each inserted CPU module
