General technical specifications
2.4 Mechanical requirements
SIMATIC TDC hardware
38 System Manual, 08/2017, A5E01114865-AL
The following table provides information on the type and scope of checks regarding
mechanical ambient conditions.
Vibrations Vibration test according to
IEC 60068-2-6 (sine)
Type of vibration: Frequency cycles with a rate of change of 1
octave/minute
10 Hz ≤ f ≤ 58 Hz, constant amplitude 0.075 mm
58 Hz ≤ f ≤ 150 Hz, constant acceleration 1 g
Duration of vibration: 10 frequency cycles per axis in each of the
3 axes which are perpendicular to each other
Shock Shock test according to
IEC 60068-2-27
Type of shock: half-sine
Strength of shock: 15 g peak value, 11 ms duration
Shock direction: 3 shocks each in +/– direction in each of the
Electromagnetic requirements (industry)
EN 61000-6-4 : 2007 + A1:2011
Using two-way radios and mobile telephones
The use of two-way radios and mobile phones in the immediate range of SIMATIC
influence the operation of the device.
